T4 Løypemaskin · drawing set NS-T4 · revision 7

The specification is a drawing

There is no table of figures on this page that is not hanging off the part it describes. Four views, front to back, in the order the machine is built.

2 050 mm over the tracks11 lamps

4 620

mm overall length

3 480

kg kerb, ready to work

190

kW peak at the tracks

32°

climbed without the winch

19

km/h in transport

Plate 2 · section through 420 mm of snow · 1:5

What one pass actually leaves behind

The tiller cuts, the teeth throw, the mat closes. Everything a skier feels the next morning is decided in the 900 mm between the back of the tracks and the trailing edge of the mat.

Fresh fall · 0 to 200 mm · −9 °CRecrystallised · −7 °CBase · laid in November, never tilled below hereTiller drum · 540 mm · 18 teeth · 320 rpmFinisher mat32 mm pitch, straight off the teeth18 mm pitch, after the mat70230 centresClassic grooves · 50 deepAbove −2 °C the mat glazes instead of closing. We stop.
Drawing NS-T4-04-S. Snow depths from the Fageråsen round, 26 January. The overlap with the previous pass is 300 mm and is cut off this view at the left.

Three details, front to back

Track unit · cab · tiller end

2 920 mm contact · 700 mm beltTensioner at 14 bar, checked weeklyDrive sprocket left, idler right · bogies free
Track unit, left side. Two bolts release a bogie; a road wheel is a trail job and the spare lives in the cab.
Eye line clears the blade at 2.1 m6.4 m² of glass · six faces · all heatedTwo seats, air suspended, 180 mm travel
Cab section looking left. The driver sits forward of the front idler so the blade edge is visible without leaning.
Hood lifts on two gas strutsSetter18 teeth · 320 rpm · mat trailing
Tiller end with the classic setter down. Teeth are changed from above with the hood up, eleven minutes a set.

Before and after · the same 300 m of trail

Forty minutes apart

The left half is the trail at 21:50, one pass of the T4 later. The right half is the same stretch at 21:10, six hours after a 180 mm fall. Same tripod position, same lens. Hover and the groomed half takes the whole frame.

Before: untouched deep snow across an open trailAfter: the same trail cut into even corduroy ridges
Fageråsen, 3 km marker · 21:10 and 21:50 · −9 °C
Winch territory32° to 45°8.0 km/h on the flat0°12°24°32° · unwinched limitkm/h0Measured loaded, tiller down, on 300 mm of settled base

Gradient · speed · the winch line

Where the T4 stops being enough

Grooming speed falls away quickly past 20°. At 32° the belts begin to slip on anything softer than a settled base, and that is the number we quote, not a brochure figure measured on hardpack in April.

If your steepest sustained climb is above 28°, buy the winch. If it is above 45°, buy a different machine from somebody else, and we will tell you who on the telephone.

Winch, € 41 200

Everything else, in one list

The figures we will stand behind

Length over blade and tiller
4 620 mm
Width over tracks · blade · tiller
2 050 · 2 600 · 2 400 mm
Height to the light bar · ground clearance
2 380 · 330 mm
Kerb mass · maximum signed-off mass
3 480 · 3 600 kg
Ground pressure, loaded
0.084 bar
Generator · battery · traction motors
48 kW · 42 kWh · 2 × 95 kW
Silent running · noise at ten metres
2 h 40 · 58 dB(A)
Diesel, working average over a season
6.1 litres an hour
Charge inlet · time to full on 32 A
Type 2, 22 kW · 2 h 10
Corduroy pitch · classic grooves
18 mm · 2 × 70 mm at 230 centres
Price, ex works Trysil
€ 268 400

Figures are from machine T4-0037 and T4-0039, measured over the 2025–26 season. Where a number moved between the two machines we publish the worse one.
